M12 Connector Cable | 5-Pin & 8-Pin A-Coded | IP67 Rated | by SICK
The M12 Connector Cable SBO-02F12-SM1 features a 5-pin female connector on head A and an 8-pin female connector on head B, making it ideal for industrial automation and PLC connections. With an IP67 rating for dust and water protection and a robust zinc die-cast locking nut, this cable ensures reliable performance in harsh environments, perfect for factory machinery and sensor applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Female connector, M12, 5-pin, A-coded
- Connection type head B: Female connector, M12, 8-pin, A-coded
- Connection type head C: Male connector, M12, 8-pin, A-coded
- Housing color: Black
- Locking nut material: Zinc die-cast, nickel-plated
- Shielding: Unshielded
- Reference voltage: ≤ 30 V DC
- Current loading: 4 A
- Enclosure rating: IP67
- Operating temperature: -30 °C to +90 °C
- Dimensions (H x L x W): 20mm x 200mm x 50mm
- Weight: 0.1 kg
Key Features
- Female connector, M12, 5-pin, A-coded on head A
- Female connector, M12, 8-pin, A-coded on head B
- Male connector, M12, 8-pin, A-coded on head C
- Zinc die-cast, nickel-plated locking nut
- Unshielded connectors
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -30°C to +90°C
- Current loading capacity of 4 A
- Reference voltage up to 30 V DC
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Industrial automation systems
- PLC connections
- Factory machinery wiring
- Sensor and actuator connections
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce replacement frequency and waste
- IP67 rating ensures protection against environmental contaminants, extending product life
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy.
Available Now
The SICK SBO-02F12-SM1 industrial connector cable is available for immediate purchase, ideal for industrial automation and PLC connection applications.
