M12 Connector Module | 4-Pin Male & 17-Pin Female Connectors | Integrated Configuration Memory | by SICK
The M12 Connector Module is designed for industrial automation systems, featuring a 4-pin male connector and dual 17-pin female connectors for local I/O. Ideal for control systems requiring reliable connections, this module ensures efficient system setup with its integrated configuration memory, making it perfect for dynamic control input applications and fieldbus integration.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- System connection: 1 x M12 male connector, 4-pin, A-coded
- Local inputs and outputs (I/O): 2 x M12 female connector, 17-pin, A-coded
- Dynamic control inputs: 2 x M12 female connector, 8-pin, A-coded
- Fieldbus, industrial network: 1 x M12 female connector, 4-pin, D-coded
- Certifications: EU declaration of conformity, UK declaration of conformity, China-RoHS, cULus certificate, China GB certificate
- Dimensions (H x L x W): 40mm x 120mm x 100mm
- Weight: 0.3 kg
Key Features
- Integrated configuration memory for efficient system setup
- System connection via 1 x M12 male connector, 4-pin, A-coded
- Local inputs and outputs through 2 x M12 female connectors, 17-pin, A-coded
- Dynamic control inputs via 2 x M12 female connectors, 8-pin, A-coded
- Fieldbus and industrial network connection with 1 x M12 female connector, 4-pin, D-coded
Professional Installation Requirements
- Installation should be performed by a qualified electrician or automation technician to ensure compliance with electrical standards and optimal system performance.
Applications
- Industrial automation systems requiring reliable system connection and voltage supply
- Control systems with local inputs and outputs
- Dynamic control input applications
- Fieldbus and industrial network integration
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Complies with China-RoHS, reducing hazardous substances in electronics
- Certified for safe and environmentally responsible use
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MICSX-CAEZMDMD1 connector module is available for immediate purchase, ideal for industrial automation and control system applications.
