M12 Magnetic Proximity Sensor | Short-body Metal Housing | 60 mm Sensing Range | IP67 Rated | by SICK
The M12 Magnetic Proximity Sensor is designed for precise proximity sensing in industrial automation, featuring a short-body metal housing and a sensing range of up to 60 mm. With a high switching frequency of 1,000 Hz and an IP67 rated enclosure, it ensures reliable performance in harsh environments, making it ideal for machinery position sensing and magnetic field detection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: M12 Magnetic Proximity Sensor | Short-body Metal Housing | 60 mm Sensing Range | IP67 Rated | by SICK
Brand: SICK
SKU: 1040069
Alternatively Known As: M12 Magnetic Proximity Sensor, Short-body Magnetic Sensor, PNP Magnetic Sensor M12
Technical Specifications
- Housing: Short-body, metal nickel-plated brass
- Thread size: M12 x 1
- Diameter: 12 mm
- Sensing range Sn: 0 mm to 60 mm
- Safe sensing range Sa: 48.6 mm
- Magnetic sensitivity: 1 mT
- Switching frequency: 1,000 Hz
- Connection type: Cable, 3-wire, 2 m PUR
- Switching output: PNP, normally open
- Electrical wiring: DC 3-wire
- Magnetic alignment: Axial
- Enclosure rating: IP67
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 2 V
- Current consumption: 10 mA
- Time delay before availability: ≤ 20 ms
- Hysteresis: 1% to 10%
- Reproducibility: ≤ 1%
- Temperature drift: ± 10%
- EMC: According to EN 60947-5-2
- Continuous current Ia: ≤ 200 mA
- Reverse polarity protection: Yes
- Short-circuit protection: Yes
- Power-up pulse protection: Yes
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- Ambient operating temperature: -25 °C to +75 °C
- Housing length: 48 mm
- Thread length: 28 mm
- Tightening torque max: 15 Nm
- Dimensions (H x L x W): 12mm x 48mm x 12mm
- Weight: 0.1 kg
Key Features
- Short-body housing with M12 x 1 thread size
- Sensing range up to 60 mm with safe sensing range of 48.6 mm
- High switching frequency of 1,000 Hz
- PNP switching output with normally open function
- IP67 rated enclosure for dust and water protection
- Cable connection type with 3-wire, 2 m PUR cable
- Reverse polarity, short-circuit, and power-up pulse protection
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature range from -25 °C to +75 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical sensor wiring and safety standards to ensure proper operation and compliance.
Applications
- Industrial automation for proximity sensing
- Magnetic field detection in manufacturing processes
- Position sensing in machinery and equipment
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable metal nickel-plated brass housing extends product lifespan reducing waste
- Energy-efficient operation with low current consumption of 10 mA
- Complies with China-RoHS environmental standards
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK MM12-60APS-ZUK Magnetic Sensor is available for immediate purchase, ideal for industrial automation and machinery position sensing applications.
