M12 Magnetic Proximity Sensor | Short-body Design | 60mm Sensing Range | IP67 Rated | by SICK
The M12 Magnetic Proximity Sensor is designed for precise position detection in industrial automation, featuring a robust short-body housing and a sensing range of up to 60 mm. With a high switching frequency of 1,000 Hz and IP67 protection, it’s perfect for harsh environments, ensuring reliable performance and durability in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: M12 Magnetic Proximity Sensor | Short-body Design | 60mm Sensing Range | IP67 Rated | by SICK
Brand: SICK
SKU: 1040070
Alternatively Known As: M12 Magnetic Sensor, Short-body Magnetic Proximity Sensor, PNP Magnetic Sensor M12
Technical Specifications
- Housing: Short-body, metal nickel-plated brass
- Thread size: M12 x 1
- Diameter: 12 mm
- Sensing range Sn: 0 mm to 60 mm
- Safe sensing range Sa: 48.6 mm
- Magnetic sensitivity: 1 mT
- Switching frequency: 1,000 Hz
- Connection type: Male connector M12, 4-pin
- Switching output: PNP, normally open
- Electrical wiring: DC 3-wire
- Magnetic alignment: Axial
- Enclosure rating: IP67
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 2 V
- Current consumption: 10 mA
- Time delay before availability: ≤ 20 ms
- Hysteresis: 1% to 10%
- Reproducibility: ≤ 1%
- Temperature drift: ± 10%
- EMC: According to EN 60947-5-2
- Continuous current Ia: ≤ 200 mA
- Reverse polarity protection: Yes
- Short-circuit protection: Yes
- Power-up pulse protection: Yes
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- Ambient operating temperature: –25 °C to +75 °C
- Housing length: 46 mm
- Thread length: 28 mm
- Tightening torque max: 15 Nm
- Dimensions (H x L x W): 12mm x 46mm x 12mm
- Weight: 0.1 kg
Key Features
- Short-body housing with M12 x 1 thread size
- Sensing range up to 60 mm with safe sensing range of 48.6 mm
- High switching frequency of 1,000 Hz
- PNP switching output with normally open function
- Robust metal nickel-plated brass housing
- IP67 rated enclosure for dust and water protection
- Reverse polarity, short-circuit, and power-up pulse protection
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature from –25 °C to +75 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for position detection
- Magnetic field sensing in manufacturing processes
- Use in harsh environments requiring IP67 protection
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable metal housing extends product life reducing waste
- Low power consumption with 10 mA current draw
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK MM12-60APS-ZCK Magnetic Sensor is available for immediate purchase, ideal for industrial automation and magnetic sensing applications.
