M12 Magnetic Proximity Sensor | Short-body Metal Housing | 60 mm Sensing Range | NPN Output | IP67 Rated | by SICK
The M12 Magnetic Proximity Sensor is designed for industrial automation, featuring a short-body metal housing and a sensing range of up to 60 mm. With an NPN switching output and a high switching frequency of 1,000 Hz, this sensor is perfect for position sensing in machinery and equipment. Its IP67 rating ensures protection against dust and water, making it reliable for various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: M12 Magnetic Proximity Sensor | Short-body Metal Housing | 60 mm Sensing Range | NPN Output | IP67 Rated | by SICK
Brand: SICK
SKU: 1040071
Alternatively Known As: M12 Magnetic Proximity Sensor, Short-body Magnetic Sensor, NPN Magnetic Sensor
Technical Specifications
- Housing: Short-body, metal nickel-plated brass
- Thread size: M12 x 1
- Diameter: 12 mm
- Sensing range Sn: 0 mm to 60 mm
- Safe sensing range Sa: 48.6 mm
- Magnetic sensitivity: 1 mT
- Switching frequency: 1,000 Hz
- Connection type: Male connector M12, 4-pin
- Switching output: NPN, normally open (NO)
- Electrical wiring: DC 3-wire
- Magnetic alignment: Axial
- Enclosure rating: IP67
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 2 V
- Current consumption: 10 mA
- Time delay before availability: ≤ 20 ms
- Hysteresis: 1% to 10%
- Reproducibility: ≤ 1%
- Temperature drift of Sr: ± 10%
- EMC: According to EN 60947-5-2
- Continuous current Ia: ≤ 200 mA
- Reverse polarity protection: Yes
- Short-circuit protection: Yes
- Power-up pulse protection: Yes
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- Ambient operating temperature: -25 °C to +75 °C
- Housing length: 46 mm
- Thread length: 28 mm
- Tightening torque max: 15 Nm
- Dimensions (H x L x W): 12mm x 46mm x 12mm
- Weight: 0.1 kg
Key Features
- Short-body housing with M12 x 1 thread size
- Sensing range up to 60 mm with safe sensing range of 48.6 mm
- NPN switching output with normally open (NO) function
- High switching frequency of 1,000 Hz
- IP67 rated enclosure for dust and water protection
- Reverse polarity, short-circuit, and power-up pulse protection
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Operating temperature range from -25 °C to +75 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for proximity sensing
- Magnetic field detection in manufacturing processes
- Position sensing in machinery and equipment
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable metal nickel-plated brass housing extends product life reducing waste
- Low power consumption with 10 mA current draw
- Complies with China-RoHS for hazardous substance reduction
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK MM12-60ANS-ZCK Magnetic Sensor is available for immediate purchase, ideal for industrial automation and proximity sensing applications.
