M12 Sensor Cable | 8-Pin Female Connector | 10m Shielded PVC | IP67 Rated | by SICK
The M12 Sensor Cable is designed for reliable industrial automation, featuring an 8-pin female connector and a 10m shielded PVC cable. With an IP67 rating, it offers excellent dust and water protection, making it ideal for factory machinery and robotics applications. This cable ensures flexible connections with flying leads, perfect for sensor and actuator wiring in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Female connector, M12, 8-pin, straight
- Connection type head B: Flying leads
- Connector material: PVC
- Locking nut material: Zinc die-cast, nickel-plated
- Cable length: 10 m
- Cable type: 8-wire, shielded PVC
- Cable diameter: 6.1 mm
- Conductor cross section: 0.25 mm²
- Current loading: 2 A
- Signal type: Sensor/actuator cable
- Enclosure rating: IP67
- Operating temperature: Flexible use +5°C to +80°C, Stationary -40°C to +80°C, Head -25°C to +90°C
- UL File No.: CYJV.E335179
- Dimensions (H x L x W): 10mm x 10000mm x 10mm
- Weight: 0.2 kg
Key Features
- Female M12, 8-pin straight connector on head A
- Flying leads on head B for flexible connection
- Shielded 8-wire PVC cable with 10 m length
- IP67 rated enclosure for dust and water protection
- Special color code for easy identification
- Operating temperature range from -40°C to +90°C depending on position
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation sensor and actuator connections
- Factory machinery wiring
- Robotics and control systems requiring reliable sensor cabling
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce replacement frequency and waste
- Shielding minimizes electromagnetic interference, improving system efficiency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK DOL-1208-G10MF sensor/actuator cable is available for immediate purchase, ideal for industrial automation and sensor connection applications.
