M12 T-Junction Connector | 4-Pin & 5-Pin Female Connectors | IP65 Rated | by SICK
M12 T-junctions are designed for reliable industrial automation and sensor connectivity, featuring a 4-pin female connector on head A and a 5-pin female connector on head B. Built with durable TPU housing and a zinc die-cast locking nut, these connectors ensure optimal performance in harsh environments, with an IP65 rating for dust and water protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Female connector, M12, 4-pin, A-coded
- Connection type head B: Female connector, M12, 5-pin, A-coded
- Connection type head C: Male connector, M12, 2-pin, A-coded
- Housing material: TPU
- Locking nut material: Zinc die-cast, nickel-plated
- Shielding: Unshielded
- Reference voltage: ≤ 60 V
- Current loading: 4 A
- Operating temperature: –25 °C to +90 °C
- Enclosure rating: IP65
- Dimensions (H x L x W): 30mm x 50mm x 50mm
- Weight: 0.1 kg
Key Features
- Female connector M12, 4-pin, A-coded on head A
- Female connector M12, 5-pin, A-coded on head B
- Male connector M12, 2-pin, A-coded on head C
- Housing made of durable TPU material
- Locking nut made of zinc die-cast, nickel-plated
- Unshielded design
- Reference voltage up to 60 V
- Current loading capacity of 4 A
- Operating temperature range from -25 °C to +90 °C
- Enclosure rating IP65 for dust and water protection
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Industrial automation and sensor connectivity
- Machine building and factory automation
- Signal transmission in harsh environments
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce replacement frequency and waste
- RoHS compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy.
Available Now
SICK T-junctions with M12 connectors are available for immediate purchase, ideal for industrial automation and sensor connectivity applications.
