M22 Red LED Indicator Light | 12-30V AC/DC | Low Power Consumption | High Shock Resistance | @Each by Eaton
The M22 Red LED Indicator Light is designed for industrial control panels, featuring a rated operational voltage of 12-30V AC/DC and low power consumption of just 0.26W. With high mechanical shock resistance and a lifespan of 100,000 hours, this LED element is perfect for machine control and signaling applications, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: M22 Red LED Indicator Light | 12-30V AC/DC | Low Power Consumption | High Shock Resistance | @Each by Eaton
Brand: Eaton
SKU: Y7-216570
Alternatively Known As: M22 Red LED Indicator Light, M22-CLED-R LED Element, Eaton M22 LED Module, Red Signal LED M22
Technical Specifications
- Rated operational voltage: 12-30 V AC/DC
- Rated operational current: 5-14 mA
- Power consumption: max 0.26 W
- Rated insulation voltage: 500 V
- Impulse withstand voltage: 6000 V AC
- Operating temperature range: -25 °C to 70 °C
- Storage temperature range: -40 °C to 80 °C
- Degree of protection: IP20
- Connection type: Front fixing, spring clamp
- Lamp type: LED
- Light color: Red
- Mechanical shock resistance: 30 g sinusoidal shock 11 ms
- Pollution degree: 3
- Radiated RFI: 10 V (IEC/EN 61131-2:2008, Level 3)
- Radio interference class: Class A (EN 55011)
- Terminal capacity (stranded): 0.5 - 2.5 mm²
- Terminal capacity (solid): 0.75 - 2.5 mm²
- Operating torque: 0.8 Nm
- Fastening type: Front fastening
- Mounting position: As required
- Dimensions (H x L x W): 39mm x 39mm x 10mm
- Weight: 0.1 kg
Key Features
- Red LED indicator light element
- Front mounting design with cage clamp connection
- Low power consumption (max 0.26 W)
- Rated operational voltage: 12-30 V AC/DC
- High mechanical shock resistance (30 g, sinusoidal shock 11 ms)
- Long electrical lifespan of 100,000 hours at 25°C
- IP20 degree of protection
- Spring clamp connection for auxiliary circuit
- Overvoltage category III
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper integration into control panels.
Applications
- Industrial control panels
- Switchgear assemblies
- Machine control and signaling
- Electrical equipment requiring LED indicator lights
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption reduces energy usage
- Long lifespan minimizes waste and replacement frequency
Warranty Information
Standard Eaton warranty applies; typically 1-3 years depending on region and application.
Available Now
The Eaton Moeller M22-CLED-R red LED element is available for immediate purchase, ideal for industrial and commercial electrical control applications.
