M23 12-Pin Receptacle | 9-Conductor Configuration | 18 AWG PVC Insulation | by Allen-Bradley
The M23 12-Pin Receptacle from Allen-Bradley features a robust 9-conductor configuration and 18 AWG PVC insulation, making it ideal for industrial automation and control systems. Designed for reliable electrical connections in manufacturing environments, this receptacle ensures compliance with IEC color coding for easy identification and is built for durability to minimize waste.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connector Type: M23 straight male receptacle
- Pin Count: 12 pins
- Conductor Count: 9 conductors
- Wire Gauge: 18 AWG
- Insulation: PVC
- Color Code: IEC standard
- Thread Size: M20 x 1.5
- Cable Length: 0.3 meters (1 ft.)
- Dimensions (H x L x W): 30mm x 300mm x 30mm
- Weight: 0.1 kg
Key Features
- M23 straight male receptacle
- 12-pin / 9-conductor configuration
- 18 AWG PVC insulated wiring
- IEC color coding for easy identification
- M20 x 1.5 thread size
- 0.3 meter (1 ft.) cable length
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety.
Applications
- Industrial automation and control systems
- Machinery and equipment wiring
- Electrical connections in manufacturing environments
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce need for frequent replacements, minimizing waste.
Warranty Information
Radwell 2-year warranty included. Factory warranty does not apply.
Available Now
The Allen-Bradley 888MM12X9AE1F M23 12-Pin Receptacle is available for immediate purchase, ideal for industrial and manufacturing electrical applications.
