M30 Proximity Sensor | NPN Output | IP68/IP69K Rated | Flush Mount | by SICK
The M30 Proximity Sensor is designed for industrial automation, featuring a sensing range of 3 mm to 16 mm and NPN output for versatile applications. With an IP68/IP69K rating, it ensures high protection against dust and water, making it ideal for manufacturing process control and machine safety. Built to withstand harsh environments, this sensor operates efficiently in temperatures ranging from -30°C to +85°C.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 36 V DC
- Current consumption: 12 mA
- Switching frequency: 50 Hz
- Voltage drop: ≤ 2 V DC
- Hysteresis: 3% to 20%
- Reproducibility: ≤ 5%
- Time delay before availability: ≤ 200 ms
- Output: NPN complementary, wire configurable
- Connection type: Male connector M12, 4-pin
- Housing material: Plastic, PBT
- Protection rating: IP68, IP69K
- Operating temperature: -30°C to +85°C
- Short-circuit and power-up pulse protection included
- Dimensions (H x L x W): 30mm x 74mm x 30mm
- Weight: 0.1 kg
Key Features
- Metric housing with M30 x 1.5 thread size
- Sensing range from 3 mm to 16 mm
- Flush installation type
- NPN switching output with complementary wire configurable function
- Male connector M12, 4-pin connection
- IP68 and IP69K rated for high protection against dust and water
- Short-circuit and power-up pulse protection
- Shock and vibration resistant according to EN 60068
- Wide ambient operating temperature range from -30°C to +85°C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and secure mounting according to manufacturer guidelines.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Machine safety and monitoring
- Material handling systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable IP68/IP69K rated housing reduces environmental contamination risk and extends product life
- Low power consumption of 12 mA supports energy-efficient operation
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK CM30-16BNP-EC1 proximity sensor is available for immediate purchase, ideal for industrial automation and manufacturing process control applications.
