M5 Countersunk Rivet | Zinc Plated Steel | High Tensile Strength | RoHS Compliant | by Wurth
The M5 Countersunk Rivet is designed for secure fastening in industrial and construction applications. With a small countersunk head for a flush finish and made from zinc plated steel, it offers excellent corrosion resistance and a high tensile fracture load of 10000 N. Ideal for metal, plastic, and composite assemblies, this rivet ensures strong, reliable joints in various environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: M5 Countersunk Rivet | Zinc Plated Steel | High Tensile Strength | RoHS Compliant | by Wurth
Brand: Wurth
SKU: 91750
Alternatively Known As: M5 Countersunk Rivet, Zinc Plated Steel Rivet, Small Head Rivet
Technical Specifications
- Thread type x nominal diameter (D): M5
- Head diameter (d1): 8.1 mm
- Outer diameter (d2): 7.0 mm
- Length (l1): 12 mm
- Head height (k1): 0.50 mm
- Min./max. grip range (s1): 0.5-3.0 mm
- Material: Steel
- Surface: Zinc plated
- RoHS-compliant: Yes
- Tensile fracture load: 10000 N
- Shear-fracture load: 3300 N
- Max. tightening torque: 6 Nm
- Drill hole diameter: 7.1 mm
- Head type: Small countersunk head
- Dimensions (H x L x W): 12mm x 12mm x 8.1mm
- Weight: 0.1 kg
Key Features
- Small countersunk head design for flush finish
- Made from zinc plated steel for corrosion resistance
- RoHS-compliant ensuring environmental safety
- High tensile fracture load of 10000 N and shear-fracture load of 3300 N
- Max tightening torque of 6 Nm for secure fastening
Professional Installation Requirements
- Installation should be performed by a qualified technician using appropriate tools to ensure correct torque and secure fastening.
Applications
- Used for fastening materials with a grip range of 0.5-3.0 mm
- Suitable for metal, plastic, and composite assemblies requiring strong, reliable joints
- Ideal for industrial, automotive, and construction fastening applications
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable zinc plating extends product life, reducing replacement frequency
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
The Wurth M5 Small Countersunk Head Rivet is available for immediate purchase, ideal for industrial and construction fastening applications.
