M5 Inductive Proximity Sensor | IP67 Rated | 5,000 Hz Switching Frequency | Stainless Steel Housing | by SICK
The M5 Inductive Proximity Sensor is designed for industrial automation, featuring a robust IP67 rated enclosure and a high switching frequency of 5,000 Hz. Ideal for object detection and position sensing in manufacturing lines, this sensor offers reliable performance with a sensing range of 0.8 mm and PNP normally open output. Built with durable stainless steel housing, it ensures longevity and efficiency in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 20%
- Voltage drop: ≤ 2 V
- Switching frequency: 5,000 Hz
- Switching output: PNP, normally open
- Connection type: Cable with M8 3-pin connector, 0.2 m length
- Enclosure rating: IP67
- Housing material: Stainless steel V2A (DIN 1.4305 / AISI 303)
- Sensing face material: Plastic, LCP
- Hysteresis: 1% to 15%
- Reproducibility: ≤ 2.5%
- Temperature drift: ≤ 10%
- Continuous current: ≤ 200 mA
- Shock resistance: 30 g, 11 ms
- Vibration resistance: 10 to 55 Hz, 1 mm
- Communication interface: IO-Link V1.1, COM2 (38.4 kBaud)
- Cycle time: 10.4 ms
- Process data length: 1 Byte
- Process data structure: Bit 0 = Sr reached, Bit 1 = Sa reached
- Dimensions (H x L x W): 25mm x 25mm x 5mm
- Weight: 0.1 kg
Key Features
- Standard design housing with M5 x 0.5 thread size
- Sensing range of 0.8 mm with safe sensing range of 0.648 mm
- Flush installation type with IP67 rated enclosure
- Switching frequency up to 5,000 Hz with PNP normally open output
- Visual adjustment indicator and IO-Link communication interface
- Robust stainless steel V2A housing and plastic sensing face
- Short-circuit and power-up pulse protection included
- Wide operating temperature range from -25°C to +70°C
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and IO-Link configuration to ensure proper operation and safety.
Applications
- Industrial automation for object detection
- Position sensing in manufacturing lines
- Metal detection in machinery
- Flush mounting in tight spaces
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable stainless steel housing extends product life reducing waste
- Low power consumption with efficient DC 3-wire electrical wiring
- IO-Link interface enables predictive maintenance reducing downtime and resource use
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK IMM05-0B8PSVR8S inductive sensor is available for immediate purchase, ideal for industrial automation and metal detection applications.
