M5 Proximity Sensor | IP67 Rated | High Switching Frequency | Flush Mount Design | by SICK
The M5 Proximity Sensor is designed for industrial automation, featuring an IP67 rated enclosure for dust and water protection, and a high switching frequency of 4,800 Hz. Ideal for machine safety and control systems, this sensor ensures reliable object detection with a sensing range of 1.5 mm, making it perfect for robotics and conveyor systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 20%
- Voltage drop: ≤ 2 V
- Time delay before availability: ≤ 10 ms
- Hysteresis: 1% to 15%
- Reproducibility: ≤ 2.5%
- Temperature drift of sensing range: ≤ 10%
- Continuous current Ia: ≤ 200 mA
- Short-circuit and power-up pulse protection included
- Shock resistance: 30 g, 11 ms
- Vibration resistance: 10 to 55 Hz, 1 mm amplitude
- Ambient operating temperature: -25 °C to +70 °C
- Housing material: Stainless steel V2A (DIN 1.4305 / AISI 303)
- Sensing face material: Plastic, LCP
- Thread length: 20 mm
- Tightening torque max: ≤ 1.5 Nm
- EMC compliant with EN 60947-5-2
- Dimensions (H x L x W): 38mm x 38mm x 5mm
- Weight: 0.1 kg
Key Features
- Standard design housing with M5 x 0.5 thread size
- Flush installation type with Ø 5 mm diameter sensing face
- Sensing range of 1.5 mm and safe sensing range of 1.215 mm
- High switching frequency of 4,800 Hz
- PNP switching output with NC output function
- Connector M8, 3-pin connection type
- IP67 rated enclosure for dust and water protection
- Visual adjustment indicator for easy setup
- Includes mounting nut and V2A stainless steel washers with locking teeth
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical wiring and sensor mounting to ensure proper function and safety.
Applications
- Industrial automation for object detection
- Machine safety and control systems
- Position sensing in manufacturing processes
- Robotics and conveyor systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable stainless steel housing reduces waste by extending product life
- Low power consumption with DC 3-wire electrical wiring
- High reliability reduces replacement frequency and electronic waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK IMM05-1B5POVT0S proximity sensor is available for immediate purchase, ideal for industrial automation and machine safety applications.
