M8 Reed Switch Sensor | Short-Body Metal Housing | IP67 Rated | 200 Hz Switching Frequency | by SICK
The M8 Reed Switch Sensor RM08-10AUO-ZUKS03 features a durable short-body metal housing with nickel-plated brass, ensuring reliability in industrial automation applications. With a magnetic sensitivity of 2.6 mT and a switching frequency of up to 200 Hz, this sensor is perfect for position sensing and machine safety. Its IP67 rating provides excellent protection against dust and water, making it ideal for harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Housing: Short-body, metal nickel-plated brass
- Thread size: M8 x 1
- Diameter: 8 mm
- Magnetic sensitivity: Typical 2.6 mT
- Switching frequency: 200 Hz
- Connection type: Cable, 2-wire, 2.5 m PUR cable
- Switching output: Reed, Normally Closed (NC)
- Electrical wiring: DC 2-wire
- Magnetic alignment: Axial
- Enclosure rating: IP67
- Supply voltage: 10 V DC to 60 V DC
- Voltage ripple: ≤ 10%
- Voltage drop: ≤ 2 V
- Hysteresis: 1% to 10%
- Temperature drift of switching distance: ±10%
- EMC: According to EN 60947-5-2
- Continuous current: ≤ 500 mA
- Shock and vibration resistance: 30 g, 11 ms / 10-55 Hz, 1 mm
- Ambient operating temperature: -25°C to +75°C
- Tightening torque max: 6 Nm
- Dimensions (H x L x W): 48mm x 48mm x 8mm
- Weight: 0.1 kg
Key Features
- Short-body metal housing with nickel-plated brass
- M8 x 1 thread size with 8 mm diameter
- Magnetic sensitivity typically 2.6 mT
- Switching frequency up to 200 Hz
- 2-wire cable connection, 2.5 m length
- Normally closed (NC) reed switch output
- IP67 rated enclosure for dust and water protection
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Wide supply voltage range from 10 V DC to 60 V DC
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor device installation to ensure proper mounting and wiring.
Applications
- Industrial automation for position sensing
- Machine safety and control systems
- Magnetic field detection in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable metal housing extends product lifespan reducing waste
- Low power consumption with DC 2-wire electrical wiring
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK RM08-10AUO-ZUKS03 Reed Switch Sensor is available for immediate purchase, ideal for industrial automation and magnetic sensing applications.
