Magnetic Position Sensor MPS-050CLTU0 | IO-Link & PNP/NPN Output | IP67 Rated | by SICK
The Magnetic Position Sensor MPS-050CLTU0 is designed for precise position sensing in industrial automation, featuring IO-Link communication and a robust IP67 rated enclosure. With a high resolution of ≥ 50 µm and repeat accuracy of 0.1 mm, it's perfect for cylinder position detection in pneumatic systems, ensuring reliable performance even in harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 12 V DC to 30 V DC
- Power consumption: 42 mA without load
- Voltage drop: ≤ 2 V
- Continuous current Ia: ≤ 100 mA
- Max load resistance: ≤ 500 Ω at 24 V
- Min load resistance: ≥ 2 kΩ
- Protection class: III
- Time delay before availability: 0.15 s
- Magnetic field sensitivity: 3 mT to 12 mT
- Resolution: ≥ 50 µm
- Linearity error: 0.3 mm
- Repeat accuracy: 0.1 mm
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection included
- Status indicator LED present
- Digital switching output and teach-in functionality
- Operating temperature: –20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- EMC compliant according to EN 60947-5-7
- Connection: 4-wire cable, 2 m length, PUR, axial outlet
- Communication interface: IO-Link V1.1, COM3, 16-bit process data
- Dimensions (H x L x W): 15mm x 65mm x 20mm
- Weight: 0.1 kg
Key Features
- C-slot cylinder type compatible with round body, profile, and tie-rod cylinders
- Measuring range of 50 mm
- Push-pull PNP/NPN switching output with analog and IO-Link output functions
- IP67 rated enclosure for dust and water protection
- Adjustable teach-in control panel for analog and digital outputs
- IO-Link V1.1 communication interface with 1 ms cycle time
- High resolution of ≥ 50 µm and repeat accuracy of 0.1 mm
- Reverse polarity and short-circuit protection
- Wide operating temperature range from –20 °C to +70 °C
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and configuration, especially for IO-Link integration.
Applications
- Industrial automation for position sensing
- Cylinder position detection in pneumatic systems
- Integration with SMC rail CDQ2 and ECDQ2 cylinders
- Use in harsh environments requiring IP67 protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient operation with low power consumption (42 mA without load)
- Durable plastic housing and PUR cable increase product lifespan and reduce waste
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK MPS-050CLTU0 Magnetic Position Sensor is available for immediate purchase, ideal for industrial automation and pneumatic cylinder position sensing applications.
