Magnetic Proximity Sensor M18 | 70mm Sensing Range | IP67 Rated | High Switching Frequency | by SICK
The Magnetic Proximity Sensor M18 is designed for precise position detection in industrial automation, featuring a sensing range of up to 70 mm and a high switching frequency of 5,000 Hz. With its robust nickel-plated brass housing and IP67 rating, this sensor ensures reliable performance in harsh environments, making it ideal for manufacturing processes and safety control systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Magnetic Proximity Sensor M18 | 70mm Sensing Range | IP67 Rated | High Switching Frequency | by SICK
Brand: SICK
SKU: 1040085
Alternatively Known As: Magnetic Proximity Sensor M18, Magnetic Sensor 70mm Range, NPN Magnetic Sensor, IP67 Magnetic Proximity Switch
Technical Specifications
- Housing: Short-body, metal nickel-plated brass
- Thread size: M18 x 1
- Diameter: 18 mm
- Sensing range Sn: 0 mm to 70 mm
- Safe sensing range Sa: 56.7 mm
- Magnetic sensitivity: 0.7 mT
- Switching frequency: 5,000 Hz
- Connection type: Cable, 3-wire, 2 m PUR
- Switching output: NPN, normally open (NO)
- Electrical wiring: DC 3-wire
- Magnetic alignment: Axial
- Enclosure rating: IP67
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 2 V
- Current consumption: 10 mA
- Time delay before availability: ≤ 20 ms
- Hysteresis: 1% to 10%
- Reproducibility: ≤ 1%
- Temperature drift: ± 10%
- EMC: According to EN 60947-5-2
- Continuous current Ia: ≤ 200 mA
- Reverse polarity protection: Yes
- Short-circuit protection: Yes
- Power-up pulse protection: Yes
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- Ambient operating temperature: -25 °C to +75 °C
- Housing length: 48 mm
- Thread length: 32 mm
- Tightening torque max: 40 Nm
- Dimensions (H x L x W): 18mm x 48mm x 18mm
- Weight: 0.1 kg
Key Features
- Short-body housing with M18 x 1 thread size
- Sensing range up to 70 mm with safe sensing range of 56.7 mm
- High switching frequency of 5,000 Hz
- NPN normally open switching output
- IP67 rated enclosure for dust and water protection
- Robust metal housing made of nickel-plated brass
- Cable connection with 3-wire, 2 m PUR cable
- Reverse polarity, short-circuit, and power-up pulse protection
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature range from -25 °C to +75 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and secure mounting according to manufacturer specifications.
Applications
- Industrial automation for position detection
- Magnetic sensing in manufacturing processes
- Safety and control systems requiring magnetic proximity detection
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable metal housing extends product lifespan reducing waste
- Energy-efficient sensor operation minimizes power consumption
- Complies with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK MM18-70ANS-ZUK Magnetic Proximity Sensor is available for immediate purchase, ideal for industrial automation and magnetic sensing applications.
