Main Switch 1 Pole 100A | IP40 Protection | DIN Rail by NHP
Main switch with 1 pole and 100A rating—ideal for residential, commercial, and light industrial applications. Built for reliable performance, with IP40 protection and DIN rail compatibility.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Main Switch 1 Pole 100A
Brand: NHP
SKU: DTMSW1100
Alternatively Known As: NHP Main Switch, 100A DIN Rail Switch, Single Pole Main Switch
Technical Specifications
- Rated Current: 100 A
- Number of Poles: 1
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: AC
- Rated Impulse Withstand Voltage (Uimp): 4 kV
- Degree of Protection: IP40
- Connectable Conductor Cross Section (Solid Core): 1-50 mm²
- Pollution Degree: 3
- Rated Surrounding Temperature Without Derating: 35 °C
- Ambient Temperature During Operating: -25-55 °C
- Dimensions (H x L x W): 85mm x 75.8mm x 17.5mm
- Weight: 0.09 kg
Key Features
- 1 Pole design for single-phase applications.
- Rated current of 100A for robust performance.
- IP40 protection rating for dust and moisture resistance.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Light industrial applications requiring reliable switching
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installation standards.
Environmental Benefits
- Efficient design reduces energy loss and enhances system reliability.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Main Switch 1 Pole 100A is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
