Trade Discount 25%
Main Switch 1 Pole 80A | IP40 Protection | DIN Rail by NHP
Main switch with 1 pole design and 80A rated current—ideal for residential, commercial, and light industrial applications. Built for reliable performance, with IP40 protection against dust and moisture.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Main Switch 1Pole 80A
Brand: NHP
SKU: DINTMS801
Alternatively Known As: NHP 80A Main Switch, DIN Rail Main Switch, 1 Pole Circuit Breaker
Technical Specifications
- Rated Current: 80 A
- Number of Poles: 1
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Service Voltage: 12 V
- Rated Impulse Withstand Voltage: 8 kV
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-50 mm²
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -5-40 °C
- Dimensions (H x L x W): 86mm x 80mm x 18mm
- Weight: 0.12 kg
Key Features
- 1 Pole design for single-phase applications.
- Rated current of 80A for reliable performance.
- IP40 protection rating for dust and moisture resistance.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Efficient design reduces energy loss and enhances safety.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Main Switch 1Pole 80A is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
