Managed PDU 1U 16A IEC C19 | 8x C13 Outlets | SNMP & Ethernet Control | Black by Eaton

BRAND: Eaton
SKU: 9001-22274
$1,500.50 List price: $1,869.80
+
Eaton's managed PDU features 8x C13 outlets and a 16A single-phase input—ideal for data centers and IT infrastructure. Built for efficient power management, it includes SNMP and Ethernet for remote monitoring and control.

Product Name/Title: Managed PDU 1U 16A IEC C19 | 8x C13 Outlets | SNMP & Ethernet Control | Black by Eaton

Brand: Eaton

SKU: 9001-22274

Alternatively Known As: Eaton Managed PDU, Eaton Rack Power Distribution Unit, Eaton ePDU 1U 16A

Technical Specifications
  • Input voltage: 200-240V
  • Amperage rating: 16A
  • Phase: Single-phase
  • Frequency rating: 50-60 Hz
  • Outlets: 8x C13
  • Input connection: C20
  • Cord length: 3m
  • Operating temperature: 0° to 60°C
  • Mounting dimension: 482.6 mm (19 inch rack standard)
  • Form factor: 1U
  • Enclosure material: Aluminum
  • Color: Black
  • Outlet control: Yes, switchable
  • SNMP and Ethernet interface for remote management
  • Display fitted for local monitoring
  • Dimensions (H x L x W): 43mm x 203mm x 482mm
  • Weight: 4.1 kg
Key Features
  • Managed PDU with outlet control and switchable outlets
  • Supports SNMP and Ethernet interface for remote monitoring
  • 1U form factor suitable for standard 19-inch rack mounting
  • Single-phase 16A input with 8x C13 outlets
  • Operating temperature range from 0° to 60°C
  • Horizontal or vertical mounting options
  • Equipped with a display for local monitoring
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and safe operation.
Applications
  • Data centers and server rooms for power distribution and management
  • IT infrastructure requiring remote power monitoring and control
  • Telecommunications equipment power management
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
  • Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
  • Enables efficient power management reducing energy waste
  • Supports remote monitoring to optimize power usage and reduce carbon footprint
Warranty Information

Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.

Available Now

The Eaton G3 ePDU MA 1U 1Phase 16A IEC C19 8XC13 is available now for immediate purchase. Ideal for data centers and IT infrastructure requiring managed power distribution.

Product specifications (skuPage.EMA07G-E.pdf, 49 Kb) [Download]
