'Matrix G4 Dimmable Tri-Colour Panel 25W 300x1200mm White Haneco'

BRAND: Haneco
SKU: MATX0312-25DIM
$145.30 List price: $193.70
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
'Haneco Matrix G4 backlit panel features 25W output, 300x1200mm size and dimmable Tri-Colour CCT. Ideal for offices and commercial ceilings.'

Alternatively Known As: Haneco Matrix G4 LED Panel, Haneco 3x12 LED Panel, Tri-Colour LED Ceiling Panel

Technical Specifications
  • Product Code: MATX0312-PS-G4
  • Power: 25 W
  • Lumen Output: 2902 / 2929 / 2802 lm at 4000K / 4500K / 5000K
  • Efficacy: 116 / 117 / 112 lm/W
  • Colour Temperature: 4000K / 4500K / 5000K selectable
  • Dimming Type: Non-dimmable according to the manufacturer datasheet
  • Mounting Type: Metric T-Bar ceiling grid
  • Input Voltage: 220–240 V AC, 50/60 Hz
  • Power Factor: Greater than 0.9
  • Beam Angle: 90°
  • Colour Rendering Index: CRI greater than 90
  • Unified Glare Rating: UGR less than 19
  • IP Rating: IP40
  • Driver: Remote driver
  • Connection Type: DC connector
  • Electrical Classification: Class II
  • Operating Temperature: -20°C to 40°C
  • Body Material: Steel
  • Diffuser Material: PMMA
  • Lifespan: Greater than 85,000 hours at Ta 40°C, L80B10
  • Surge Protection: Overload and short-circuit protection
  • Fascia Colour: White, RAL 9003
  • Dimensions (H x L x W): 33mm x 1195mm x 295mm
  • Weight: 2.3 kg
Key Features
  • Tri-tone CCT selection from 4000K, 4500K and 5000K
  • Low-glare illumination with UGR less than 19
  • High-efficiency output exceeding 110 lm/W
  • CRI greater than 90 for accurate colour rendering
  • Flicker-free driver
  • Cyanosis-compliant for suitable healthcare applications
  • Designed for metric T-Bar ceiling grids
  • Suitable for offices, classrooms and commercial interiors
Professional Installation Requirements
  • Installation and mains electrical connection should be completed by a licensed electrician in accordance with the manufacturer's instructions and applicable Australian wiring requirements.
Applications
  • Offices and open-plan workplaces
  • Boardrooms and meeting rooms
  • Classrooms and education facilities
  • Showrooms and function areas
  • Storage rooms
  • Medical and healthcare facilities
  • Commercial suspended ceiling systems
Standards & Compliance
  • AS/NZS 60598.1 for general luminaire safety requirements
  • AS/NZS 60598.2.2 for recessed luminaires
Environmental Benefits
  • High efficacy helps reduce electricity consumption compared with less efficient fluorescent or LED alternatives
  • Long projected service life of more than 85,000 hours can reduce replacement frequency and product waste
  • Tri-tone selection allows the light output to be matched to the application without replacing the fitting
  • Green Star-compliant design contribution for applicable building projects
Warranty Information

5-year direct replacement warranty against manufacturing defects, subject to Haneco warranty terms. Installation by a licensed electrician and proof of purchase and installation may be required.

Available Now

Available through Haneco and authorised Australian electrical wholesalers and distributors.
