'Matrix G4 Panel Tri-Colour 40W 300x1200mm 1-10V White Haneco'

BRAND: Haneco
SKU: MATX0312-H10VD
$164.70 List price: $219.60
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
'Haneco Matrix G4 backlit panel features tri-colour CCT, 40W output and 300x1200mm size with 1-10V dimmable driver in white. Ideal for office ceiling grids.'

Alternatively Known As: Haneco Matrix G4 LED Panel, Haneco 300 x 1200mm LED Panel, Tri-CCT LED Ceiling Panel

Technical Specifications
  • Power: 40 W
  • Dimming Type: 1-10 V
  • Colour Temperature: 4000 K / 4500 K / 5000 K
  • Input Voltage: 220–240 V AC, 50/60 Hz
  • Mounting Type: Metric T-bar ceiling grid
  • IP Rating: IP40
  • Colour Rendering Index: CRI >90
  • Unified Glare Rating: UGR <19
  • Beam Angle: 90°
  • Driver: Remote driver
  • Electrical Classification: Class II
  • Body Material: Steel
  • Diffuser Material: PMMA
  • Flicker-Free: Yes
  • Cyanosis Compliance: Yes
  • Product Lifespan: More than 85,000 hours at Ta 40°C, L80B10
  • Finish: White RAL 9003
  • Dimensions (H x L x W): 33mm x 1195mm x 295mm
  • Weight: 2.3 kg
Key Features
  • Tri-colour selectable lighting with 4000 K, 4500 K and 5000 K settings
  • 1-10 V dimmable driver for commercial lighting control systems
  • Low-glare output with UGR below 19
  • High colour rendering with CRI above 90
  • Flicker-free driver technology
  • Backlit panel construction for even illumination and improved heat dissipation
  • Suitable for metric T-bar ceiling grids
  • White finish for office and commercial interiors
  • Designed for education, workplace and medical lighting applications
Professional Installation Requirements
  • Installation and mains connection must be completed by a licensed or suitably qualified electrician in accordance with the manufacturer's instructions, AS/NZS 3000 and applicable local regulations. A compatible 1-10 V control system is required for dimming.
Applications
  • Office ceiling grids
  • Classrooms and education facilities
  • Showrooms and retail areas
  • Boardrooms and meeting rooms
  • Function areas
  • Storage rooms
  • Medical and healthcare facilities
  • Commercial interior lighting
Standards & Compliance
  • AS/NZS 60598 series for luminaires
  • AS/NZS 3000 for electrical installation and wiring practices
Environmental Benefits
  • High luminous efficacy helps reduce electricity consumption compared with less efficient commercial lighting technologies
  • Long projected service life of more than 85,000 hours can reduce replacement frequency and material waste
  • Flicker-free, dimmable operation supports efficient lighting control and reduced energy use
  • Steel body components can be recovered through established metal recycling streams
  • Greenstar-compliant design can contribute to sustainable building lighting objectives
Warranty Information

5-year product warranty, subject to installation in accordance with Haneco instructions and applicable conditions.

Available Now

Available through Haneco and authorised Australian electrical and lighting distributors.
