'Matrix G4 Tridonic DALI LED Panel 40W 300x1200mm White Haneco'

BRAND: Haneco
SKU: MATX0312-TDALI
$199.50 List price: $266.00
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
'Haneco Matrix G4 LED backlit panel features 40W output, 300x1200mm size and Tridonic DALI dimmable Tri-Colour CCT. Ideal for commercial fitouts.'

Alternatively Known As: Haneco MATRIX G4 TDALI LED Panel, MATX0312-G4-TDALI, 40W DALI LED Backlit Panel, Tri-CCT LED Panel

Technical Specifications
  • Rated Power: 40 W
  • Dimming Type: DALI with Tridonic driver
  • Colour Temperature: 4000 K / 4500 K / 5000 K
  • Lumen Output: 4222 lm / 4695 lm / 4514 lm by CCT
  • Efficacy: 108 lm/W / 126 lm/W / 117 lm/W by CCT
  • Input Voltage: 220–240 V AC, 50/60 Hz
  • Power Factor: >0.9
  • Beam Angle: 90°
  • Colour Rendering Index: >90
  • Unified Glare Rating: <19
  • IP Rating: IP40, front face
  • Electrical Classification: Class II
  • Body Material: Steel
  • Diffuser Material: PMMA
  • Driver: Remote Tridonic DALI driver
  • Lifespan: >85,000 hours at Ta 40°C, L80B10
  • Operating Temperature: -20°C to 40°C
  • Mounting Type: Metric T-bar ceiling grid
  • Dimensions (H x L x W): 33mm x 1195mm x 295mm
  • Weight: 2.3 kg
Key Features
  • Tri-colour CCT selection from a single panel
  • Tridonic DALI driver for digital lighting control
  • Low-glare design with UGR below 19
  • Flicker-free illumination
  • High colour rendering for accurate colour definition
  • Cyanosis-compliant for suitable medical applications
  • Suitable for commercial and education fitouts
  • Remote driver connection
  • White finish with nominal 300 x 1200mm panel format
Professional Installation Requirements
  • Installation must be performed by a licensed or suitably qualified electrician in accordance with the manufacturer's instructions, local wiring requirements and applicable Australian standards. Isolate the mains supply before wiring or maintenance.
Applications
  • Commercial offices
  • Classrooms and education facilities
  • Showrooms and retail spaces
  • Boardrooms and meeting rooms
  • Function areas and hotel common areas
  • Storage and manufacturing facilities
  • Medical facilities requiring low-glare, high-colour-rendering lighting
Standards & Compliance
  • AS/NZS 60598.1:2017, Luminaires – General requirements and tests
  • AS/NZS 60598.2.2:2016, Particular requirements for recessed luminaires
  • AS/NZS 61347.1:2016, Lamp controlgear – General and safety requirements
  • AS/NZS 61347.2.13:2018, Controlgear for LED modules
  • AS CISPR 15:2017, Radio disturbance characteristics of electrical lighting and similar equipment
Environmental Benefits
  • LED technology provides high luminous efficacy, reducing energy consumption compared with conventional fluorescent panels
  • Long projected service life can reduce replacement frequency and material waste
  • Steel body and PMMA diffuser can be separated for appropriate recycling at end of life
  • DALI dimming enables lighting levels to be matched to occupancy and daylight, supporting further energy savings
Warranty Information

5-year product warranty under Haneco's direct replacement warranty programme, subject to the manufacturer's warranty terms and correct installation by a licensed electrician.

Available Now

Available through Haneco and authorised Australian electrical wholesalers and distributors.
