MCB 25A 3P C Curve 10kA Breaking Capacity DIN Rail Mounted Eltech

BRAND: Eltech
SKU: DN3C25H
$64.14 List price: $85.53
1 1 ($64.14 per 1)
+ −
30 Days Return Electricians Unlock Trade Access
MCB 25A 3P C Curve circuit breaker with a 10kA breaking capacity—ideal for power distribution and circuit protection.
Technical Specifications
  • Rated Current: 25A
  • Poles: 3
  • Tripping Curve: C Curve
  • Breaking Capacity: 10kA
  • Mounting: DIN Rail
  • Standards Compliance: IEC/EN 60898-1
  • Dimensions (H x L x W): 85mm x 70mm x 54mm
  • Weight: 0.3 kg
Key Features
  • 25 Ampere current rating
  • 3 Pole configuration for three-phase systems
  • C Curve tripping characteristic for general use
  • 10kA short circuit breaking capacity
Professional Installation Requirements
  • Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
  • Power distribution panels
  • Industrial electrical systems
  • Commercial and residential circuit protection
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Helps prevent electrical fires and damage by quickly interrupting fault currents
  • Supports energy efficiency by protecting electrical equipment from overload
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Eltech MCB 25A 3P C Curve 10kA is available for immediate purchase, ideal for use in power distribution and circuit protection applications.

Data Sheet (media.nl, 367 Kb) [Download]
