MCB DX3 3 Pole 16A Curve C | 36kA Breaking Capacity | IP20 Protection | @EA of 1 | by Legrand
The MCB DX3 3 Pole 16A Curve C is a reliable miniature circuit breaker designed for residential and small commercial electrical panels. With a breaking capacity of 36kA and IP20 protection, it ensures safety and efficiency in circuit protection. Ideal for electricians, this device features a mechanical indicator for contact status and is compatible with various cable types, making it a versatile choice for any installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: MCB DX3 3 Pole 16A Curve C | 36kA Breaking Capacity | IP20 Protection | @EA of 1 | by Legrand
Brand: Legrand
SKU: 410021
Alternatively Known As: Miniature Circuit Breaker 3P 16A C Curve, Legrand DX3 MCB 3 Pole 16 Amp, 3 Pole Circuit Breaker 16A C Curve
Technical Specifications
- Rated current: 16 A
- Number of poles: 3
- Rated voltage: 400 V AC
- Breaking capacity: 36 kA at 400 V
- Tripping curve: C
- Rated insulation voltage Ui: 500 V
- Rated impulse withstand voltage Uimp: 6 kV
- Frequency: 50-60 Hz
- Degree of protection: IP20
- Pollution degree: 3
- Connectable conductor cross section: 1.5-35 mm² multi-wired, 1.5-50 mm² solid-core
- Mounting method: DIN rail
- Mechanical indicator for contact status
- Halogen free
- Degree of impact strength: IK02
- Operating ambient temperature: -25 to 70 °C
- Storage temperature: -40 to 70 °C
- Dimensions (H x L x W): 128mm x 79mm x 80mm
- Weight: 0.3 kg
Key Features
- Breaking capacity 36kA according to IEC 60947-2
- Tripping threshold between 80A and 160A (C curve)
- IP20 protection against solid bodies larger than 12.5mm
- Red/green mechanical indicator for contact status
- Can be equipped with Legrand DX3 auxiliaries and accessories
- Compatible with copper and aluminium cables with accessories
- Halogen free design
- Label holder for clear circuit identification
- Mounting on DIN rail
Professional Installation Requirements
- Installation should be performed by a qualified electrician in compliance with local electrical installation standards to ensure safety and proper operation.
Applications
- Residential and small commercial electrical panels
- Protection of electrical circuits in homes and small businesses
- Circuit protection in distribution boards
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Designed with halogen-free materials to reduce environmental impact
- Complies with substance-restriction requirements for safer disposal
- Manufactured with environmentally conscious processes
Warranty Information
Warranty terms as per Legrand standard product warranty policy. Typically 2 years against manufacturing defects.
Available Now
The Legrand MCB DX3 3 Pole 16A Curve C Miniature Circuit Breaker is available for immediate purchase, ideal for residential and small commercial electrical panel protection.
