MCB Eaton Chassis Flat Pan | 30 Pole | 18mm Spacing | 250A Capacity | by Tobin
The MCB Eaton Chassis Flat Pan is designed for secure mounting of up to 30 poles with 18mm spacing, rated for a robust 250A current capacity. Ideal for electrical distribution panels and industrial switchgear assemblies, this steel chassis features a corrosion-resistant finish, ensuring durability and compliance with AS/NZS 3000 standards. Perfect for both commercial and residential circuit protection, it supports efficient electrical distribution and enhances system longevity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Pole Count: 30
- Pole Spacing: 18mm
- Current Rating: 250A
- Material: Steel chassis with corrosion-resistant finish
- Compatibility: Eaton MCBs
- Mounting Type: Flat pan
- Dimensions (H x L x W): 50mm x 100mm x 540mm
- Weight: 3 kg
Key Features
- Flat pan chassis design for secure mounting
- Supports up to 30 poles with 18mm spacing
- Rated for 250A current capacity
- Compatible with Eaton MCBs
- Robust construction for durability
Professional Installation Requirements
- Installation should be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Electrical distribution panels
- Industrial switchgear assemblies
- Commercial and residential circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enables efficient electrical distribution reducing energy losses
- Supports modular circuit protection enhancing system longevity
Warranty Information
1 year warranty covering manufacturing defects.
Available Now
The MCB Eaton Chassis Flat Pan 30 Pole 18mm 250A by Tobin is available for immediate purchase, ideal for electrical switchgear and distribution panel assembly.
