MCB UL1077 10kA 3P+N 20A C Curve Certified Circuit Breaker by Allen-Bradley
The MCB UL1077 10kA 3P+N 20A C Curve is a reliable miniature circuit breaker designed for effective electrical circuit protection. With a 20A rated current and a C Curve trip characteristic, it’s perfect for industrial, commercial, and residential applications. This UL1077 certified breaker ensures safety and compliance, helping to prevent electrical fires and equipment damage.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Miniature Circuit Breaker 20A, 3P+N MCB, C Curve Circuit Breaker
Technical Specifications
- Standard: UL1077
- Rated Current: 20 Amperes
- Poles: 3P+N
- Trip Curve: C Curve
- Breaking Capacity: 10kA
- Voltage Rating: Typically up to 415V AC
- Dimensions (H x L x W): 85mm x 75mm x 70mm
- Weight: 0.3 kg
Key Features
- Miniature Circuit Breaker (MCB) with UL1077 certification
- Rated current: 20A
- C Curve trip characteristic for moderate inrush currents
- 3 Pole plus Neutral (3P+N) configuration
- Short circuit breaking capacity: 10kA
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Industrial electrical panels
- Commercial electrical distribution
- Residential circuit protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Helps prevent electrical fires and equipment damage by reliable circuit interruption
- Supports energy efficiency by protecting electrical circuits from overload
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley MCB UL1077 10kA 3P+N 20A C Curve is available for immediate purchase, ideal for electrical circuit protection in industrial, commercial, and residential settings.
