MCB UL1077 10kA 3P+N 7A D Curve High Inrush Current Protection UL1077 Compliant by Allen-Bradley
The MCB UL1077 10kA 3P+N 7A D Curve is designed for reliable circuit protection in industrial, commercial, and residential applications. With a 10kA breaking capacity and D Curve tripping characteristic, it effectively handles high inrush currents, ensuring safety and compliance with UL1077 standards. Ideal for licensed electricians, this circuit breaker helps prevent electrical fires and equipment damage.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Miniature Circuit Breaker 3P+N 7A D Curve, UL1077 MCB, Allen-Bradley Circuit Breaker
Technical Specifications
- Rated Current: 7A
- Poles: 3P+N
- Breaking Capacity: 10kA
- Tripping Curve: D Curve
- Standard: UL1077
- Voltage Rating: Typically up to 415V AC
- Dimensions (H x L x W): 85mm x 70mm x 72mm
- Weight: 0.3 kg
Key Features
- 10kA short circuit breaking capacity
- 3 Pole plus Neutral configuration
- 7 Ampere rated current
- D Curve tripping characteristic for high inrush currents
- UL1077 standard compliance for supplementary protection
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards and proper operation.
Applications
- Industrial electrical panels
- Commercial electrical distribution
- Residential electrical protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Helps prevent electrical fires and equipment damage by reliable circuit protection
- Supports energy efficiency by minimizing downtime and electrical faults
Warranty Information
1 year manufacturer warranty covering defects in materials and workmanship.
Available Now
The Allen-Bradley MCB UL1077 10kA 3P+N 7A D Curve is available for immediate purchase, ideal for electrical protection in industrial, commercial, and residential electrical systems.
