MCB UL1077 30A D Curve 10kA Breaking Capacity 3P+N Configuration by Allen-Bradley
The MCB UL1077 30A D Curve is a reliable miniature circuit breaker designed for high inrush current applications. With a breaking capacity of 10kA and a 3P+N configuration, it’s perfect for industrial, commercial, and residential circuit protection. This UL1077 certified device ensures safety and compliance, making it an essential component for electrical panels and distribution systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Miniature Circuit Breaker 30A D Curve, 3P+N MCB, UL1077 Circuit Breaker
Technical Specifications
- Standard: UL1077
- Rated Current: 30 Amperes
- Poles: 3P+N
- Trip Curve: D Curve
- Breaking Capacity: 10kA
- Voltage Rating: 230/400V AC
- Dimensions (H x L x W): 85mm x 65mm x 70mm
- Weight: 0.3 kg
Key Features
- Miniature Circuit Breaker (MCB) with UL1077 certification
- Rated current: 30A
- Trip curve: D Curve for high inrush current applications
- 3 Pole plus Neutral (3P+N)
- Breaking capacity: 10kA
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Industrial electrical panels
- Commercial electrical distribution
- Residential circuit protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Protects electrical circuits to prevent damage and reduce fire risk
- Supports energy efficiency by preventing electrical faults
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley MCB UL1077 10kA 3P+N 30A D Curve is available for immediate purchase, ideal for industrial, commercial, and residential circuit protection.
