MCB UL1077 50A D Curve | 10kA Breaking Capacity | 3P+N Configuration | by Allen-Bradley
The MCB UL1077 50A D Curve is a reliable miniature circuit breaker designed for industrial and commercial electrical protection. With a breaking capacity of 10kA and a 3P+N configuration, it effectively handles high inrush currents, ensuring safety and compliance in electrical installations. Ideal for protecting circuits in machinery and equipment, this MCB is UL1077 certified for peace of mind.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Miniature Circuit Breaker 50A D Curve, 3P+N MCB, UL1077 Circuit Breaker
Technical Specifications
- Standard: UL1077
- Rated Current: 50 Amperes
- Poles: 3 Pole + Neutral
- Trip Curve: D Curve
- Breaking Capacity: 10kA
- Voltage Rating: Typically up to 415V AC
- Dimensions (H x L x W): 85mm x 70mm x 72mm
- Weight: 0.3 kg
Key Features
- Miniature Circuit Breaker (MCB) with UL1077 certification
- Rated current: 50A
- Trip curve: D Curve suitable for high inrush currents
- 3 Pole plus Neutral (3P+N) configuration
- Breaking capacity: 10kA
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards and proper operation.
Applications
- Industrial electrical panels
- Commercial electrical distribution
- Protection of electrical circuits in machinery and equipment
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Helps prevent electrical fires and equipment damage by providing reliable circuit protection
- Supports energy efficiency by minimizing downtime and electrical faults
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley MCB UL1077 10kA 3P+N 50A D Curve is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
