Terasaki TemBreak 2 MCCB 125 Frame 125kA 4P 63A Thermal Magnetic

MCCB 125 Frame 4P 63A | 125kA Breaking Capacity | Thermal Magnetic by NHP

BRAND: NHP

SKU: H125NJ463

$2,905.80 List price: $3,858.60

+ −

30 Days Return Delivery Options

MCCB with 125 frame and 4 poles, offering 63A rated current and 125kA breaking capacity—ideal for industrial power distribution. Built for reliable protection, with thermal magnetic release and adjustable trip curves.

Description
Attachments

Product Name/Title: Terasaki TemBreak 2 MCCB 125 Frame 125kA 4P 63A Thermal Magnetic

Brand: NHP

SKU: H125NJ463

Alternatively Known As: MCCB, Thermal Magnetic Circuit Breaker, Power Switching Circuit Breaker

Technical Specifications

Rated Current: 63 A
Number of Poles: 4
Max Rated Operation Voltage: 690 V
Rated Ultimate Short Circuit Breaking Capacity: 125 kA
Rated Service Short Circuit Breaking Capacity: 80 kA
Rated Insulation Voltage: 800 V
Rated Impulse Withstand Voltage: 8 kV
Electrical Life: 10,000 cycles
Mechanical Life: 20,000 cycles
Cable Cross Section Range: 35-185 mm²
Pollution Degree: 3
Rated Surrounding Temperature: 50 °C
Maximum Operating Temperature: 70 °C
Dimensions (H x L x W): 165mm x 151mm x 140mm
Weight: 1.3 kg

Key Features

Thermal/magnetic release for reliable protection
Adjustable thermal and magnetic trip curves
High short-circuit breaking capacity of 125 kA

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Power distribution and protection in commercial and industrial settings
General: Suitable for various electrical installations requiring circuit protection

Standards & Compliance

Complies with AS/NZS 60950 for safety and performance standards.

Environmental Benefits

Designed for long electrical and mechanical life, reducing waste and resource consumption.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Terasaki TemBreak 2 MCCB 125 Frame 125kA 4P 63A Thermal Magnetic is available now for immediate purchase. Ideal for industrial applications requiring reliable circuit protection.

Non-Returnable & Non-Cancellable

H125NJ463-AU-TB2-MCCB-Datasheet.pdf (H125NJ463-AU-TB2-MCCB-Datasheet.pdf, 2,153 Kb) [Download]
