MCCB 140G H Frame 50kA 3P 90A Adjustable Thermal Magnetic | by Allen-Bradley
The MCCB 140G H Frame 50kA 3P 90A Adjustable Thermal Magnetic Circuit Breaker is designed for industrial and commercial electrical protection. With a high breaking capacity of 50kA and an adjustable thermal magnetic trip unit, it ensures precise protection for three-phase systems. Ideal for use in electrical panels and motor control centers, this circuit breaker meets IEC and Australian standards for safety and reliability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Molded Case Circuit Breaker 140G, Adjustable Thermal Magnetic MCCB, 3 Pole Circuit Breaker 90A
Technical Specifications
- Rated Current: 90A
- Poles: 3
- Breaking Capacity: 50kA
- Frame Size: H
- Trip Unit: Adjustable Thermal Magnetic
- Voltage Rating: Up to 600V AC
- Standards Compliance: IEC and relevant Australian standards
- Dimensions (H x L x W): 140mm x 110mm x 90mm
- Weight: 3.5 kg
Key Features
- Adjustable thermal magnetic trip unit for precise protection
- High breaking capacity of 50kA for enhanced safety
- 3-pole design suitable for three-phase systems
- H frame size for compatibility with various panel configurations
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with safety standards and proper operation.
Applications
- Industrial electrical panels
- Commercial power distribution
- Motor control centers
- Protection of electrical circuits in manufacturing plants
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Helps prevent electrical fires and equipment damage, reducing waste and environmental hazards
- Durable design extends product life, minimizing replacement frequency
Warranty Information
1 year limited warranty covering manufacturing defects.
Available Now
The Allen-Bradley MCCB 140G H Frame 50kA 3P 90A Adjustable Thermal Magnetic Circuit Breaker is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
