MCCB 160A 4P Non Auto Switch | 690V Max | Compact Design by NHP
MCCB with 160A rated current and 4 poles—ideal for industrial and commercial power distribution. Built for manual operation, with a compact design for easy integration and compliance with AS/NZS 3000 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Terasaki TemBreak PRO MCCB 160 Frame 4P 160A Non Auto Switch
Brand: NHP
SKU: P160D24160NN
Alternatively Known As: Terasaki Circuit Breaker, MCCB 160A, Non Auto MCCB
Technical Specifications
- Rated current: 160 A
- Number of poles: 4
- Max rated operation voltage: 690 V
- Rated frequency: 50-60 Hz
- Rated insulation voltage: 800 V
- Short time withstand current: 2 kA
- Electrical life: 10,000 cycles
- Mechanical life: 20,000 cycles
- Cable cross section range: 1.5-70 mm²
- Pollution degree: 3
- Rated surrounding temperature: 50 °C
- Maximum operating temperature: 70 °C
- Dimensions (H x L x W): 130mm x 95.5mm x 120mm
- Weight: 1.3 kg
Key Features
- Rated current: 160 A
- 4 poles for versatile applications
- Non auto-switch type for manual operation
- Suitable for isolation and front-side connection
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution in manufacturing facilities
- Commercial: Electrical panels in commercial buildings
- General: Protection of electrical circuits in various applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
- Designed for high efficiency, reducing energy loss and operational costs.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Terasaki TemBreak PRO MCCB 160 Frame 4P 160A Non Auto Switch is available now for immediate purchase. Ideal for industrial and commercial electrical systems.
