MCCB 160A 4P Non Auto Switch | 690V Max | Front-Side Connection by NHP
MCCB with 160A rated current and 4 poles—ideal for industrial and commercial power distribution. Built for manual operation, with front-side connection and high efficiency to reduce energy loss.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Terasaki TemBreak PRO MCCB 160 Frame 4P 160A Non Auto Switch
Brand: NHP
SKU: A160D14160NN
Alternatively Known As: MCCB, Circuit Breaker, Power Switching Circuit Breaker
Technical Specifications
- Rated Current: 160 A
- Number of Poles: 4
- Max Rated Operation Voltage: 690 V
- Rated Insulation Voltage: 800 V
- Short Time Withstand Current: 2 kA
- Rated Impulse Withstand Voltage: 8 kV
- Electrical Life: 10,000 cycles
- Mechanical Life: 20,000 cycles
- Cable Cross Section Range: 1.5-70 mm²
- Rated Frequency: 50-60 Hz
- Max Operating Temperature: 70 °C
- Storage Temperature: -10-70 °C
- Dimensions (H x L x W): 130mm x 95.5mm x 100mm
- Weight: 1.3 kg
Key Features
- Rated current of 160 A with 4 poles.
- Non auto-switch type for manual operation.
- Suitable for isolation and front-side connection.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution in manufacturing facilities
- Commercial: Electrical panels in commercial buildings
- General: Protection of electrical circuits in various applications
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Designed for high efficiency, reducing energy loss during operation.
Warranty Information
Standard warranty as per manufacturer’s policy.
Available Now
The Terasaki TemBreak PRO MCCB 160 Frame 4P 160A Non Auto Switch is available now for immediate purchase. Ideal for industrial and commercial electrical systems.
