MCCB 4P 16A | 150kA Breaking Capacity | Fixed Thermal Magnetic by NHP
MCCB with 16A rated current and 150kA breaking capacity—ideal for industrial and commercial power distribution. Built for enhanced protection, with fixed thermal magnetic trip unit.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 140G MCCB H Frame 150kA 4P 16A Fixed Thermal Magnetic
Brand: NHP
SKU: 140GH15C4C16
Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Circuit Breaker 16A, Thermal Magnetic Circuit Breaker
Technical Specifications
- Rated current: 16 A
- Number of poles: 4
- Max rated operation voltage: 690 V
- Rated insulation voltage: 1000 V
- Rated frequency: 50-60 Hz
- Electrical life: 8000 cycles
- Mechanical life: 25000 cycles
- Power loss: 5.2 W
- Rated impulse withstand voltage: 8 kV
- Dimensions (H x L x W): 130mm x 116mm x 120mm
- Weight: 1.6 kg
Key Features
- Rated ultimate short circuit breaking capacity of 150 kA at 415 V.
- Fixed thermal and magnetic trip unit for enhanced protection.
- Suitable for isolation and reverse connection of supply.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution and protection in manufacturing facilities
- Commercial: Electrical systems in commercial buildings
- General: Any application requiring reliable circuit protection
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Designed for high performance and reliability, reducing the risk of electrical failures.
Warranty Information
Standard warranty applies, please check with the supplier for details.
Available Now
The Allen-Bradley 140G MCCB H Frame 150kA 4P 16A Fixed Thermal Magnetic is available now for immediate purchase. Ideal for industrial and commercial electrical systems.
