MCCB G Frame 36kA 4P 25A | Fixed Thermal Magnetic | 690V by NHP

BRAND: NHP
SKU: 140GG2C4C25
$211.10 List price: $280.30
+ −
30 Days Return Delivery Options
MCCB with 36kA breaking capacity and 4 poles—ideal for industrial motor control and commercial electrical distribution. Built for reliable circuit protection, with fixed thermal and magnetic trip units.

Product Name/Title: Allen-Bradley 140G MCCB G Frame 36kA 4P 25A Fixed Thermal Magnetic

Brand: NHP

SKU: 140GG2C4C25

Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Circuit Breaker 25A

Technical Specifications
  • Rated Current: 25 A
  • Number of Poles: 4
  • Max Rated Operation Voltage: 690 V
  • Rated Ultimate Short Circuit Breaking Capacity: 36 kA
  • Rated Service Short Circuit Breaking Capacity: 36 kA
  • Type of Protection: Thermal/magnetic release
  • Trip Curve: Fixed thermal, fixed magnetic
  • Frame Size Rating: 160 A
  • Rated Frequency: 50-60 Hz
  • Rated Insulation Voltage: 800 V
  • Rated Short Circuit Breaking Capacity (ICU): 6 kA at 690 V AC
  • Rated Short Circuit Breaking Capacity (ICS): 4.5 kA at 690 V AC
  • Rated Impulse Withstand Voltage: 8 kV
  • Electrical Life: 8000 cycles
  • Mechanical Life: 25000 cycles
  • Power Loss: 8 W
  • Suitable for DIN rail mounting.
  • Dimensions (H x L x W): 130mm x 101mm x 101.2mm
  • Weight: 1.4 kg
Key Features
  • Fixed thermal and magnetic trip unit for reliable protection.
  • Rated short circuit breaking capacity of 36 kA at 415 V.
  • Suitable for isolation and reverse connection of supply.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Motor control and protection
  • Commercial: Electrical distribution systems
  • General: Any application requiring reliable circuit protection
Standards & Compliance
  • Complies with relevant Australian standards for electrical safety.
Environmental Benefits
  • Designed for high performance and reliability, reducing the need for frequent replacements.
Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The Allen-Bradley 140G MCCB G Frame 36kA 4P 25A Fixed Thermal Magnetic is available now for immediate purchase. Ideal for industrial and commercial electrical systems.

Non-Returnable & Non-Cancellable

140GG2C4C25-AU-140G-MCCB-G-Frame-Datasheet.pdf (140GG2C4C25-AU-140G-MCCB-G-Frame-Datasheet.pdf, 316 Kb) [Download]
