Allen-Bradley 140G MCCB G Frame 50kA 4P 80A Fixed Thermal Magnetic

MCCB G Frame 50kA 4P 80A | Fixed Thermal Magnetic | High Breaking Capacity by NHP

BRAND: NHP

SKU: 140GG3C4C80

$677.40 List price: $899.40

+ −

30 Days Return Delivery Options

MCCB with 80A current and 4 poles—ideal for industrial motor control and commercial electrical distribution. Built for reliable protection, with fixed thermal magnetic trip and 50kA breaking capacity.

Description
Attachments

Product Name/Title: Allen-Bradley 140G MCCB G Frame 50kA 4P 80A Fixed Thermal Magnetic

Brand: NHP

SKU: 140GG3C4C80

Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Thermal Magnetic Circuit Breaker

Technical Specifications

Rated Current: 80 A
Number of Poles: 4
Max Rated Operation Voltage: 690 V
Rated Ultimate Short Circuit Breaking Capacity: 50 kA
Rated Service Short Circuit Breaking Capacity: 37.5 kA
Rated Frequency: 50-60 Hz
Rated Insulation Voltage: 800 V
Electrical Life: 8000 cycles
Mechanical Life: 25000 cycles
Power Loss: 19.2 W
Rated Surrounding Temperature: 40 °C
Maximum Operating Temperature: 75 °C
Storage Temperature: -40-80 °C
Dimensions (H x L x W): 130mm x 101mm x 101.2mm
Weight: 1.4 kg

Key Features

Fixed thermal and magnetic trip unit for reliable protection.
High breaking capacity of 50 kA at 415 V.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Motor control and protection
Commercial: Electrical distribution systems

Standards & Compliance

Complies with AS/NZS 3000 for electrical installations.

Environmental Benefits

Designed for high efficiency, reducing energy loss and improving system reliability.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 140G MCCB G Frame 50kA 4P 80A Fixed Thermal Magnetic is available now for immediate purchase. Ideal for industrial and commercial electrical distribution systems.

Non-Returnable & Non-Cancellable

140GG3C4C80-AU-140G-MCCB-G-Frame-Datasheet.pdf (140GG3C4C80-AU-140G-MCCB-G-Frame-Datasheet.pdf, 316 Kb) [Download]
