MCCB H Frame 65kA 3P 160A | Electronic LSI | High Breaking Capacity by NHP
MCCB H Frame with 65kA breaking capacity and electronic LSI—ideal for industrial motor control and commercial electrical distribution. Built for precise protection, with high efficiency and reduced energy loss.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 140G MCCB H Frame 65kA 3P 160A Electronic LSI
Brand: NHP
SKU: 140GH6H3D16
Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Electronic Circuit Breaker
Technical Specifications
- Rated Current: 160 A
- Number of Poles: 3
- Max Rated Operation Voltage: 690 V
- Rated Ultimate Short Circuit Breaking Capacity: 70 kA
- Rated Service Short Circuit Breaking Capacity: 70 kA
- Trip Curve: LSI
- Rated Frequency: 50-60 Hz
- Rated Insulation Voltage: 1000 V
- Electrical Life: 8000 cycles
- Mechanical Life: 25000 cycles
- Power Loss: 25.4 W
- Rated Impulse Withstand Voltage: 8 kV
- Dimensions (H x L x W): 130mm x 116mm x 90mm
- Weight: 1.2 kg
Key Features
- Electronic release trip unit for precise protection.
- High breaking capacity of 70 kA at 415 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor control and protection
- Commercial: Electrical distribution systems
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Designed for high efficiency, reducing energy loss and improving system reliability.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 140G MCCB H Frame 65kA 3P 160A Electronic LSI is available now for immediate purchase. Ideal for industrial and commercial electrical systems.
Non-Returnable & Non-Cancellable
