MCCB H Frame 70kA 4P 160A | Electronic LSI | Compact Design by NHP

BRAND: NHP
SKU: 140GH6H4D16
$2,664.50 List price: $3,538.20
+ −
30 Days Return Delivery Options
MCCB H Frame with 70kA breaking capacity and electronic LSI—ideal for industrial power distribution. Built for precise protection, with compact design for easy integration.

Product Name/Title: Allen-Bradley 140G MCCB H Frame 70kA 4P 160A Electronic LSI

Brand: NHP

SKU: 140GH6H4D16

Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Circuit Breaker 160A

Technical Specifications
  • Rated Current: 160 A
  • Number of Poles: 4
  • Max Rated Operation Voltage: 690 V
  • Rated Ultimate Short Circuit Breaking Capacity: 70 kA
  • Rated Service Short Circuit Breaking Capacity: 70 kA
  • Type of Protection Trip Unit: Electronic release
  • Trip Curve: LSI
  • Long Time Overload Protection Adjustment Range: 64-160 A
  • Instantaneous Protection Adjustment Range: 160-1600 A
  • Rated Frequency: 50-60 Hz
  • Rated Insulation Voltage: 1000 V
  • Rated Short Circuit Breaking Capacity (ICU): 15 kA
  • Rated Short Circuit Breaking Capacity (ICS): 15 kA
  • Short Time Protection Adjustment Range: 160-1600 A
  • Rated Impulse Withstand Voltage: 8 kV
  • Electrical Life: 8000 cycles
  • Power Loss: 33.8 W
  • Mechanical Life: 25000 cycles
  • Rated Surrounding Temperature: 40 °C
  • Maximum Operating Temperature: 75 °C
  • Storage Temperature: -40-80 °C
  • Max Altitude Before Derating: 2000 m
  • Dimensions (H x L x W): 130mm x 116mm x 120mm
  • Weight: 1.6 kg
Key Features
  • Electronic release trip unit for precise protection.
  • Rated short circuit breaking capacity of 70 kA.
  • Suitable for isolation and reverse connection of supply.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Power distribution and protection in commercial and industrial settings
  • General: Suitable for isolation and circuit protection in various electrical installations
Standards & Compliance
  • Complies with relevant Australian standards for electrical safety and performance.
Environmental Benefits
  • Designed for high performance and reliability in various environmental conditions.
Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The Allen-Bradley 140G MCCB H Frame 70kA 4P 160A Electronic LSI is available now for immediate purchase. Ideal for industrial and commercial electrical installations.
