MCCB R Frame 125kA 4P 2500A | High Breaking Capacity | Isolation & Reverse Connection by NHP
MCCB R Frame with 2500A rated current and 4 poles—ideal for industrial and commercial power distribution. Built for high breaking capacity and reliable isolation, ensuring protection from overloads and short circuits.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 140G MCCB R Frame 125kA 4P 2500A Moulded Case Switch Isolator
Brand: NHP
SKU: 140GR12S4E25
Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Circuit Breaker Isolator
Technical Specifications
- Rated current: 2500 A
- Number of poles: 4
- Max rated operation voltage: 690 V
- Rated ultimate short circuit breaking capacity: 80 kA
- Rated service short circuit breaking capacity: 60 kA
- Type of protection trip unit: Non auto-switch
- Frame size rating: 3000 A
- Rated frequency: 50-60 Hz
- Rated insulation voltage: 1000 V
- Rated short circuit breaking capacity: 40 kA at 690 V AC
- Rated impulse withstand voltage: 12 kV
- Short time withstand current: 40 kA for 1 sec
- Power loss: 292 W
- Rated surrounding temperature: -40 to 40 °C
- Maximum operating temperature: 75 °C
- Storage temperature: -40 to 80 °C
- Max altitude before derating: 2000 m
- Dimensions (H x L x W): 382mm x 284.5mm x 554mm
- Weight: 25 kg
Key Features
- Rated current of 2500 A with 4 poles.
- High breaking capacity of 80 kA at 415 V.
- Suitable for isolation and reverse connection of supply.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution in manufacturing facilities
- Commercial: Electrical installations in large buildings
- General: Protection of electrical circuits from overloads and short circuits
Standards & Compliance
- Complies with AS/NZS 60950 for safety of electrical equipment.
Environmental Benefits
- Designed for high efficiency, reducing energy loss and improving system reliability.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 140G MCCB R Frame 125kA 4P 2500A Moulded Case Switch Isolator is available now for immediate purchase. Ideal for industrial and commercial electrical installations.
