Micro 4Pin Connector | 4-6mm DC | IP67 Rated | Gold Contacts by NHP
Micro 4Pin connector with 4-6mm DC capacity and IP67 rating—ideal for industrial and commercial applications. Built for reliable connections, with gold contact surface for enhanced conductivity and durability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: AB Pre Wired Connection System Terminal Chamber 4 to 6mm DC Micro 4Pin Male Straight
Brand: NHP
SKU: 871ATS4DM
Alternatively Known As: Micro 4Pin Connector, Pre Wired Terminal Chamber, DC Connector
Technical Specifications
- Rated Current: 4 A
- Rated Voltage: 250 V
- Contact Type: Pin
- Degree of Protection: IP67
- Material of Contact Surface: Gold
- Material Housing: Plastic
- Diameter Connector: 6 mm
- Dimensions (H x L x W): 30mm x 50mm x 50mm
- Weight: 0.2 kg
Key Features
- IP67 rated for protection against dust and water ingress.
- Gold contact surface for enhanced conductivity and durability.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Suitable for various industrial applications requiring reliable connections.
- Commercial: Ideal for use in commercial electrical systems.
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The AB Pre Wired Connection System Terminal Chamber 4 to 6mm DC Micro 4Pin Male Straight is available now for immediate purchase. Ideal for industrial and commercial applications.
