Mini Control Relay 2NO 2NC | 12VDC Coil | 10A 690V | DIN-Rail by NHP
Mini control relay with 2 normally open and 2 normally closed contacts—ideal for industrial automation systems. Built for control circuits, with 10A current and 690V voltage, featuring efficient 12VDC coil power.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CS8 Relay 12VDC Coil 2NO 2NC Contact
Brand: NHP
SKU: CS8C22Z12VDC
Alternatively Known As: Mini Control Relay, Contactor Relay, CS8 Relay
Technical Specifications
- Number of auxiliary contacts as normally closed: 2
- Number of auxiliary contacts as normally open: 2
- Rated operation current (Ie) at 400 V: 10 A
- Max rated operation voltage (Ue) AC: 690 V
- Voltage type for actuating: DC
- Control supply voltage (Us) at DC: 12 V
- Power consumption DC coil pickup: 3 W
- Power consumption DC coil hold-in: 3 W
- Mounting method: DIN-rail/screw
- Connection type auxiliary circuit: Screw connection
- Dimensions (H x L x W): 56mm x 53mm x 45mm
- Weight: 0.2 kg
Key Features
- Mini control relay with 2 normally open and 2 normally closed contacts.
- Rated operation current of 10 A and maximum rated operation voltage of 690 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial automation systems
- Control circuits for machinery
- Building management systems
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient power consumption with low coil power requirements.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Relay 12VDC Coil 2NO 2NC Contact is available now for immediate purchase. Ideal for industrial automation and control applications.
Non-Returnable & Non-Cancellable
