Mini Control Relay 48VAC Coil | 3NO 1NC Contacts | Screw Connection by NHP
Mini control relay with 48VAC coil, featuring 3 normally closed and 1 normally open contact—ideal for industrial automation and commercial HVAC systems. Built for easy installation with screw connections, ensuring reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CS8 Relay 48VAC Coil 3NO 1NC Contact
Brand: NHP
SKU: CS831Z48VAC
Alternatively Known As: Control Relay, Mini Relay, Switching Relay
Technical Specifications
- Nominal Current: 6 A
- Number of Normally Closed Contacts: 3
- Number of Normally Open Contacts: 1
- Voltage Type for Actuating: AC
- Control Supply Voltage at AC 50 Hz: 48 V
- Control Supply Voltage at AC 60 Hz: 48 V
- Type of Electric Connection: Screw connection
- Degree of Protection: IP20
- Dimensions (H x L x W): 30mm x 50mm x 50mm
- Weight: 0.5 kg
Key Features
- Mini control relay with 3 normally closed contacts and 1 normally open contact.
- Screw connection for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Relay 48VAC Coil 3NO 1NC Contact is available now for immediate purchase. Ideal for industrial and commercial control applications.
Non-Returnable & Non-Cancellable
