Mini Plug-in Timer 4C/O 24VAC | 4 Changeover Contacts | LED Status Indication | by Clipsal
The Mini Plug-in Timer 4C/O 24VAC is designed for versatile switching with its 4 changeover contacts, making it ideal for industrial automation, HVAC control, and lighting circuits. With a reliable electromechanical design and LED status indication, this timer relay ensures efficient operation and energy-saving automation in commercial settings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Mini Plug-in Timer 4C/O 24VAC | 4 Changeover Contacts | LED Status Indication | by Clipsal
Brand: Clipsal
SKU: SCHREXL4TMB7
Alternatively Known As: Timer Relay, Plug-in Timer, 4C/O Timer Relay, 24VAC Timer, Clipsal Timer Relay, SCHREXL4TMB7
Technical Specifications
- Contact configuration: 4 changeover (4C/O)
- Coil voltage: 24VAC
- Contact rating: 8A at 250VAC
- Mounting: Plug-in base (DIN rail or panel)
- Status indication: LED
- Operating temperature: -20°C to +55°C
- Electrical life: 100,000 operations
- Mechanical life: 10,000,000 operations
- Dimensions (H x L x W): 78mm x 80mm x 22.5mm
- Weight: 0.15 kg
Key Features
- Miniature plug-in timer relay
- 4 changeover (4C/O) contacts for versatile switching
- 24VAC operating voltage
- DIN rail or panel mounting capability
- LED status indication
- High switching capacity
- Reliable electromechanical design
Professional Installation Requirements
- Installation by a licensed electrician is required to ensure compliance with Australian electrical standards and safe operation.
Applications
- Industrial automation panels
- HVAC control systems
- Lighting control circuits
- Pumping and irrigation systems
- General electrical control applications
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables energy-saving automation by controlling equipment run times
- Reduces unnecessary power consumption in industrial and commercial settings
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Mini Plug-in Timer 4C/O 24VAC (SCHREXL4TMB7) is available for immediate purchase. Ideal for automation, lighting, and control applications in industrial and commercial environments.
