Mini Relay 4C/O 24VDC | 4 Changeover Contacts | 6A Contact Rating | by Clipsal
The Mini Relay 4C/O 24VDC is a compact plug-in relay designed for versatile switching in industrial automation and building management systems. With 4 changeover contacts and a reliable 6A contact rating, it ensures optimal performance in various electrical control applications. Ideal for qualified electricians, this relay features a mechanical indicator for easy status inspection and a durable design for long-lasting use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Mini Relay 4C/O 24VDC | 4 Changeover Contacts | 6A Contact Rating | by Clipsal
Brand: Clipsal
SKU: SCHRXM4AB1BD
Alternatively Known As: Harmony RXM relay, 4 pole changeover relay, 24VDC plug-in relay, RXM4AB1BD relay, industrial control relay
Technical Specifications
- Contact configuration: 4 C/O (4PDT)
- Coil voltage: 24V DC
- Contact rating: 6A at 250V AC/30V DC
- Mechanical indicator: Yes
- Plug-in mounting
- Dielectric strength: 2500V AC between coil and contacts
- Operating temperature: -40°C to +55°C
- Electrical life: 100,000 cycles (at rated load)
- Mechanical life: 10,000,000 cycles
- Dimensions (H x L x W): 38mm x 28mm x 21mm
- Weight: 0.1 kg
Key Features
- Miniature plug-in relay for compact installations
- 4 changeover (C/O) contacts for versatile switching
- 24V DC coil voltage
- 6A contact rating for reliable performance
- Harmony RXM series for high durability
- Transparent cover for easy status inspection
- Mechanical indicator for contact position
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure correct wiring and safety compliance.
Applications
- Industrial automation control panels
- Building management systems
- Lighting control circuits
- HVAC systems
- General electrical switching applications
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Compact design reduces material usage
- Long electrical life minimizes replacement waste
- Low power consumption coil for energy efficiency
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal Mini Relay 4C/O 24VDC (SCHRXM4AB1BD) is available for immediate purchase. Ideal for industrial automation, building management, and electrical control applications.
