Trade Discount 33%
Miniature Circuit Breaker 100A 2P | D Curve | 15kA Breaking Capacity | IP20 by Clipsal
Miniature circuit breaker with 100A rated current and D curve—ideal for small commercial and residential distribution systems. Built for safety and reliability, with 15kA breaking capacity and IP20 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Acti9, Miniature circuit breaker (MCB), C120H, 2P, 100A, D curve, 15000A (IEC/EN 60898-1), 15kA (IEC/EN 60947-2)
Brand: Clipsal
SKU: A9N18502
Alternatively Known As: MCB, Miniature Circuit Breaker, Circuit Protection Device
Technical Specifications
- Rated current: 100A at 30°C
- Rated operational voltage: 380...415V AC 50/60Hz, 220...240V AC 50/60Hz, 440V AC 50/60Hz, <= 250V DC
- IP Rating: IP20
- Mechanical durability: 20,000 cycles
- Electrical durability: 5,000 cycles
- Pollution degree: 3
- Overvoltage category: IV
- Rated insulation voltage: 500V AC 50/60Hz
- Rated impulse withstand voltage: 6kV
- Dimensions (H x L x W): 81mm x 73mm x 54mm
- Weight: 0.41 kg
Key Features
- Thermal-magnetic trip unit technology.
- Breaking capacity of 15kA.
- Suitable for isolation.
- Clip-on mounting support for 35 mm DIN rail.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Small commercial and residential distribution systems.
Standards & Compliance
- Complies with EN/IEC 60898-1 and EN/IEC 60947-2 standards.
Environmental Benefits
- Complies with environmental regulations and standards.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal Acti9 Miniature Circuit Breaker (MCB) C120H 100A 2P D Curve is available now for immediate purchase. Ideal for small commercial and residential distribution systems.
