Miniature Circuit Breaker 10kA 1 Pole | 13A D Curve | IP40 Rated by NHP
Miniature circuit breaker with 10kA breaking capacity and 13A D curve—ideal for residential and commercial circuit protection. Built for high inrush current applications, with compact DIN rail design and IP40 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 10kA 1 Pole 13A D Curve
Brand: NHP
SKU: DTM10113D
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
Technical Specifications
- Rated Current: 13 A
- Number of Poles: 1
- Trip Curve: D
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Rated Short Circuit Breaking Capacity: 10 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 0.75-35 mm²
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Ambient Temperature: -25 to 55 °C
- Dimensions (H x L x W): 85mm x 75mm x 17.5mm
- Weight: 0.12 kg
Key Features
- 10kA short circuit breaking capacity
- D curve for high inrush current applications
- Compact design for DIN rail mounting
- IP40 rated for protection against solid objects
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small electrical installations
- Commercial: Offices and retail spaces requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
- Enhances electrical safety, reducing the risk of fire hazards.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Miniature Circuit Breaker MCB 10kA 1 Pole 13A D Curve is available now for immediate purchase. Ideal for residential and commercial electrical installations.
Non-Returnable & Non-Cancellable
