NHP DIN-T Miniature Circuit Breaker MCB 10kA 2 Pole 6A D Curve

Miniature Circuit Breaker 10kA 2 Pole | 6A D Curve | IP40 Protection by NHP

BRAND: NHP

SKU: DTM10206D

$160.60 List price: $213.30

+ −

30 Days Return Delivery Options

Miniature circuit breaker with 10kA breaking capacity and 6A D curve—ideal for residential, commercial, and light industrial applications. Built for high inrush current protection, with IP40 rating for enhanced safety.

Description
Attachments

Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 10kA 2 Pole 6A D Curve

Brand: NHP

SKU: DTM10206D

Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device

Technical Specifications

Rated Current: 6 A
Number of Poles: 2
Trip Curve: D
Rated Voltage: 415 V
Frequency: 50-60 Hz
Voltage Type: DC
Rated Short Circuit Breaking Capacity: 10 kA
Degree of Protection: IP40
Connectable Conductor Cross Section: 0.75-35 mm²
Rated Insulation Voltage: 440 V
Rated Impulse Withstand Voltage: 4 kV
Pollution Degree: 3
Rated Surrounding Temperature: 30 °C
Dimensions (H x L x W): 85mm x 75mm x 35mm
Weight: 0.23 kg

Key Features

10kA short circuit breaking capacity
D curve for high inrush current applications
IP40 protection rating

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small buildings
Commercial: Offices and retail spaces
Industrial: Light industrial applications requiring circuit protection

Standards & Compliance

Complies with AS/NZS 60898 and AS/NZS 60947 for safety and performance standards.

Environmental Benefits

Enhances electrical safety, reducing the risk of fire hazards.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Miniature Circuit Breaker MCB 10kA 2 Pole 6A D Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.

DTM10206D-AU-MCB-10kA-2P-D-Curve-Datasheet.pdf (DTM10206D-AU-MCB-10kA-2P-D-Curve-Datasheet.pdf, 208 Kb) [Download]
