NHP DIN-T Miniature Circuit Breaker MCB 10kA 3 Pole 0.5A D Curve

Miniature Circuit Breaker 10kA 3 Pole | 0.5A D Curve | IP40 Rated by NHP

BRAND: NHP

SKU: DTM10305D

$179.10 List price: $237.80

+ −

30 Days Return Delivery Options

Miniature circuit breaker with 10kA breaking capacity and 0.5A D curve—ideal for industrial, commercial, and residential applications. Built for high inrush current protection, with IP40 rating for solid object protection.

Description
Attachments

Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 10kA 3 Pole 0.5A D Curve

Brand: NHP

SKU: DTM10305D

Alternatively Known As: Miniature Circuit Breaker, MCB, 3 Pole Circuit Breaker, D Curve MCB

Technical Specifications

Rated Current: 5 A
Number of Poles: 3
Trip Curve: D
Rated Voltage: 415 V
Frequency: 50-60 Hz
Voltage Type: DC
Rated Short Circuit Breaking Capacity: 10 kA
Degree of Protection: IP40
Connectable Conductor Cross Section: 0.75-35 mm²
Rated Insulation Voltage: 440 V
Rated Impulse Withstand Voltage: 4 kV
Pollution Degree: 3
Rated Surrounding Temperature: 30 °C
Dimensions (H x L x W): 85mm x 75mm x 52.5mm
Weight: 0.34 kg

Key Features

10kA short circuit breaking capacity.
D curve for high inrush current applications.
3 poles for three-phase systems.
IP40 rated for protection against solid objects.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Machinery and equipment protection
Commercial: Electrical distribution systems
Residential: Circuit protection in homes

Standards & Compliance

Complies with AS/NZS 60898 for circuit breakers.

Environmental Benefits

Reduces the risk of electrical fires and equipment damage.
Promotes energy efficiency by preventing overloads.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Miniature Circuit Breaker MCB 10kA 3 Pole 0.5A D Curve is available now for immediate purchase. Ideal for industrial, commercial, and residential applications.

Non-Returnable & Non-Cancellable

DTM10305D-AU-MCB-10kA-3P-D-Curve-Datasheet.pdf (DTM10305D-AU-MCB-10kA-3P-D-Curve-Datasheet.pdf, 224 Kb) [Download]
