Miniature Circuit Breaker 10kA 3Pole | 4A D Curve | IP40 Rated by NHP
Miniature circuit breaker with 10kA breaking capacity and 4A D curve—ideal for industrial, commercial, and residential circuit protection. Built for high inrush current applications, with IP40 rating for solid object protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley Miniature Circuit Breaker UL1077 10kA 3Pole 4A D Curve
Brand: NHP
SKU: 1492SPM3D040
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
Technical Specifications
- Rated Current: 4 A
- Number of Poles: 3
- Trip Curve: D
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Rated Short Circuit Breaking Capacity: 15 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-35 mm² (solid), 1-25 mm² (multi-wired)
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature: -25 to 55 °C
- Dimensions (H x L x W): 80mm x 67mm x 52.5mm
- Weight: 0.34 kg
Key Features
- 10kA breaking capacity for reliable circuit protection.
- D curve for high inrush current applications.
- IP40 rated for protection against solid objects.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Machinery and equipment protection
- Commercial: Electrical distribution systems
- Residential: Circuit protection in homes
Standards & Compliance
- Complies with AS/NZS 60947.2 for circuit breakers.
Environmental Benefits
- Enhances safety in electrical installations, reducing fire hazards.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley Miniature Circuit Breaker UL1077 10kA 3Pole 4A D Curve is available now for immediate purchase. Ideal for industrial, commercial, and residential applications.
