Miniature Circuit Breaker 2-Pole 6A | C Tripping Characteristic | 6 kA Switching Capacity | IP20 by Eaton
Miniature circuit breaker with 2 poles and a 6A rated current—ideal for residential and commercial switchgear applications. Built for safety and reliability, featuring a C tripping characteristic and 6 kA rated switching capacity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Miniature Circuit Breaker 2-Pole 6A | C Tripping Characteristic | 6 kA Switching Capacity | IP20 by Eaton
Brand: Eaton
SKU: Y7-242874
Alternatively Known As: Miniature Circuit Breaker 6A, 2-Pole MCB, Eaton PLS6/M, xPole PLS6 MCB
Technical Specifications
- Number of poles: 2
- Tripping characteristic: C
- Rated current (In): 6 A
- Rated switching capacity (IEC/EN 60898-1): 6 kA
- Rated operational voltage (Ue): 400 V AC max
- Rated insulation voltage (Ui): 440 V
- Rated impulse withstand voltage (Uimp): 4 kV
- Frequency rating: 50-60 Hz
- Degree of protection: IP20
- Connectable conductor cross section (solid and multi-wired): 1 mm² to 25 mm²
- Ambient operating temperature: -25 °C to 75 °C
- Heat dissipation: 2.9 W current-dependent
- Current limiting class: 3
- Dimensions (H x L x W): 73mm x 85mm x 35mm
- Weight: 0.24 kg
Key Features
- 2-pole miniature circuit breaker with tripping characteristic C
- Rated current: 6 A
- Rated switching capacity IEC/EN 60898-1: 6 kA
- Rated operational voltage up to 400 V AC
- Rated insulation voltage: 440 V
- Impulse withstand voltage: 4 kV
- Pollution degree 2 and overvoltage category III
- IP20 degree of protection
- Connectable conductor cross section from 1 mm² to 25 mm²
- Ambient operating temperature range from -25 °C to 75 °C
- Current limiting class 3
- Additional equipment possible
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with electrical safety standards and proper integration into switchgear.
Applications
- Switchgear for residential applications
- Switchgear for commercial applications
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant ensuring reduced hazardous substances
- Energy efficient circuit protection reducing electrical faults and energy waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Eaton's official warranty policy for details.
Available Now
The Eaton Moeller series xPole PLS6/M 2-pole miniature circuit breaker 6A is available now for immediate purchase. Ideal for residential and commercial electrical switchgear applications.
